GE Carescape B450 Flex-3S2P 18650 2062895-001 Original Medical Battery

£153.08 £183.70 Inc Tax

GTIN: N/A SKU: web 02379 Categories: , ,


Euro Energy Part Number: 02379
GE Carescape B450 Flex-3S2P 18650, 2062895-001 Original Medical Battery
GE Part Number: 18650 / 2062895-001 Original Medical Battery
Voltage/Capacity: 10.8V
Approx Size: 152mm L x 58.7mm W x 21.8mm H
Approx Weight: 310g
Chemistry: Lithium Rechargeable (Li-Ion)

This is an original GE battery, 18650 / 2062895-001, for the GE Carescape B450.

The highly portable CARESCAPE* Monitor B450 is a flexible-acuity monitor that keeps the flow of vital data moving.

The CARESCAPE Monitor B450 is well suited for all flexible-acuity care areas where size and portability are a concern, including emergency departments, recovery rooms, and step-down units. Its wireless capabilities and portable design, powered by the 2062895-001 rechargeable lithium ion battery, help match the needs of high-acuity patients during intra-hospital transport and stay with your patient virtually anywhere, giving you continuous monitoring every step of the way. In combination mode, the CARESCAPE Monitor B450 enables comprehensive monitoring during early mobility of telemetry patients and facilitates a smooth transition from high-acuity units to lower-acuity areas.

CARESCAPE B450 Features

The CARESCAPE Monitor B450 is an important component of the CARESCAPE monitoring platform. It is a lightweight bedside monitor that is robust enough to meet changing patient acuity and care area needs as well as capable of maintaining all bedside monitoring functions during intra-hospital transport.

  • Battery strength indicator LED light for 2062895-001 lithium ion battery
  • Back-up AC power
  • Documents and stores events
  • Shock advisory option
  • Adjustable heart rate alarms
  • ECG Monitor
  • External Paddles
  • Recorder
  • Alarms and Code Summary
  • Biomedically Inspected
  • Patient Ready

CARESCAPE B450 Specifications


  • 7.9”H x 11.8”W x 15.6”L/20 x 30 x 39.7 cm)


  • 5.0 kg (11.0 lb) with all options and battery, without modules

Power Supply / Battery

Power Supply

  • Universal input voltage range: 100 to 240 Vac /-10%, 50/60 Hz
  • Power consumption: < 200 VA
  • Protection class: Class I
  • Grounding: Hospital grade
  • Cooling: Natural convection – no fans

Battery (Optional)

  • Type: Exchangeable Lithium-Ion, part number 2062895-001
  • Number of batteries: 1 or 2
  • Voltage: 10.8 V (nominal)
  • Capacity: 3.8 Ah per battery, 7.6 Ah with 2 batteries (min)
  • Charge time: 2 to 3 hours per battery, depending on configuration
  • Run time: 3.5 hours, depending on configuration
  • Battery life: 300 cycles to 60% capacity

Technical Specifications


  • Size: 12 in (diagonal)
  • Type: Active matrix colour TFT LCD
  • Resolution: 1024 x 768 pixels (XGA)
  • Number of traces: 6 (max)
  • Sweep speed: 0.625, 6.25, 12.5, 25, 50 mm/sec
  • Configuration: Automatic configuration according to parameter availability.
  • Manual configuration with up to 8 user- configurable profiles for care specific configurations, and up to 6 user-configurable display pages for each profile


  • Touch screen: Standard
  • Power on: Front of unit
  • Remote control (USB): Optional 11 keys to facilitate non-touch use: Alarm Setup, Monitor Setup, Procedures, Trends, Data & Pages, Print Waveforms, Freeze/ Snapshot, NIBP Auto, NIBP Start/ Stop, Parameters and Zero ALL Pressures

Operating Conditions

  • Temperature: 10 to 35°C (50 to 95°F)
  • Relative Humidity: 10 to 90% non-condensing

Storage Conditions

  • Temperature: -20 to 60°C (-4 to 140°F)
  • Relative Humidity: 10 to 90% non-condensing

More information on the CARESCAPE B450

The CARESCAPE* Monitor B450 is an important component of the CARESCAPE monitoring platform. It is a lightweight bedside monitor that is robust enough to meet changing patient acuity and care area needs as well as capable of maintaining all bedside monitoring functions during intra-hospital transport.

Exceptional clinical Excellence

  • Enables you to use a wide parameter set with its compatibility with the CARESCAPE Patient Data Module (PDM), Patient Side Module (E-PSM) as well as single-width E-modules
  • Consistent, innovative algorithms aid in accurate diagnoses, including Datex-Ohmeda sidestream CO2, 12SL* diagnostic ECG with direct two-way MUSE* ECG communication, DINAMAP* SuperSTAT NIBP, Entropy*, BIS**, and your choice of GE TruTrak *, Masimo SET** or Nellcor** OxiMax** SpO2

Light weight, intuitive design and simplified servicing

  • Especially developed for the intra-hospital transport of patients, with the capability to attach and detach GE hemodynamic modules, E-PSM(P) or CARESCAPE Patient Data Module.
  • Designed for flexible acuity care settings, the Pages and Profiles functionality may increase workflow efficiency by allowing you to configure the monitor to unit standards and patient populations
  • Exceptional alarm functionality enables remote bed-to bed viewing (Auto View on Alarms), quick adjustment to all parameter limits, defining parameter limit range(s), preventing specific alarms from being turned off and set adjustments to meet patient changing conditions may help optimize your workflow and reduce alarm fatigue
  • Dedicated software and parameters for the OR, PACU, Critical Care, Emergency Care, and NICU care areas make it easier to configure to your work patterns
  • Remote service through InSite* ExC provides updates and predictive maintenance to assist your BioMed servicing capabilities

Dependable data continuity and integration

  • Provides continuous hemodynamic measurement during intra-hospital transport and also transfers trend data with the CARESCAPE Patient Data Module
  • Wireless connectivity with GE’s CARESCAPE Gateway enables communications to EMR systems through standard HL7 protocol
  • Eases workflow and enables patient mobility with telemetry and combination monitoring capability
  • Provides a peer-to-peer networking option that allows monitors to communicate and view information from other GE CARESCAPE monitors
  • Supports networking with other GE Healthcare products including CARESCAPE CIC Pro, iCentral, MUSE* ECG database, Unity Network* ID and other products that run on the CARESCAPE Network

For further information on this GE Healthcare Original Medical battery or to discuss our range of Original Manufacturer medical batteries & Compatible medical batteries, Original Manufacturer medical accessories and general purpose Sealed Lead Acid/VRLA batteries contact our friendly & knowledgeable Customer Service team on 0116 2340567 or email

Additional information

Weight 0.31 kg
Dimensions 15 × 6 × 2 cm
