DeVilbiss VacuAide Quiet Suction Unit 7314P-614 Original Medical Battery

£83.58 £100.30 Inc Tax

GTIN: N/A SKU: web 02368 Categories: , ,


Euro Energy Part Number: 02368
DeVilbiss VacuAide Quiet Suction Unit 7314P-614 Original Medical Battery
DeVilbiss Battery Number: 7314P-614
Chemistry: Sealed Lead Acid
Voltage/Capacity: 12V
Approx Size: 86mm L x 66mm W x 105mm H
Approx Weight: 1090g

This is a genuine original battery for use in the DeVilbiss VacuAide Quiet Suction Unit, part number 7314P-614.

The VacuAide Quiet Suction Unit from DeVilbiss provides unmatched performance and safety in the airway suction device category with reliable, portable operation in very quiet unit. Offering a 50% sound reduction, the VacuAide QSU offers the quietest high suction/high flow portable unit on the market. Portable power is delivered from the sealed lead acid 7314P-614 original DeVilbiss battery, Euro Energy part number 02368. The DeVilbiss VacuAide QSU can be used for airway clearance for both children and adults and can be used for both clinical and home use. It offers exceptional low noise levels and is simple to operate using a single on/off switch and suction setting between 50mmHg and 550mmHg with an easy-grip adjustment dial. It’s clear and easy to read display indicates both power status and level of battery charge, to notify the User when the 7314P-614 sealed lead acid DeVilbiss battery original DeVilbiss, Euro Energy part number 02368 needs recharging.

Features and Benefits

  • Low noise level without compromising suction performance
  • Lightweight unit weighing just 2kg
  • High performance capabilities with a vacuum range of 50 – 550 mmHg and a flow range of up to 27 l/min
  • Comes complete with multi voltage power supply
  • Multi voltage switch mode power supply allows operation on any AC voltage 100V – 240V.
  • Simple on/off operation
  • Large, rotating, easy grip pressure adjustment gauge allows the user to easily view and set the required suction pressure
  • Single use 800ml collection bottle with bacterial filter integrated into the lid for ease of replacement. Canister lid made from a flexible material making it easy for the carer to remove
  • Optional 1200ml reusable, autoclavable collection bottle
  • Built to comply with the ISO 10079-1 standard for non transport use.


  • Dimensions (H x W x D): 21.1 x 20.3 x 21.6 cm
  • Weight : 3 kg
  • Vacuum range : 50 – 550 mmHg
  • Operating sound level: 55dBA
  • Air Flow : 27 l/min
  • Collection container capacity: 800ml (disposable), 1200ml (reusable)
  • Internal battery (7314P-614, Euro Energy part number 02368) run time: 60 minutes
  • Operating temperature range: 0°C – 40°C
  • Electrical requirements: 100-240V, 50-60 Hz
  • ISO classification: EN ISO 10079-1 : 2009

For further information on this DeVilbiss Original Medical battery or to discuss our range of Original Manufacturer medical batteries & Compatible medical batteries, Original Manufacturer medical accessories and general purpose Sealed Lead Acid/VRLA batteries contact our friendly & knowledgeable Customer Service team on 0116 2340567 or email

Additional information

Weight 1.09 kg
Dimensions 8.6 × 6.6 × 10.5 cm
