Datex S5 Compact Anaesthesia Compatible Medical Battery

£82.08 £98.50 Inc Tax

GTIN: N/A SKU: web EE090178 Category: Tag:


Euro Energy Part Number: EE090178
Datex S5 Compact Anaesthesia Compatible Medical Battery
Original Part Number: 17014-HEL
Voltage / Capacity: 12.0 Volt 3.6 Ah
Dimensions: 86mm (L) x 18mm (W) x 137mm (H)
Approx. Weight: 605g
Chemistry: Nickel Metal Hydride (Ni-MH)

This is a compatible medical battery for use in the Datex S5 Compact Anaesthesia. Built in the UK by Euro Energy, this battery comes with a 12 month warranty.

2 batteries are required per Anaesthesia unit.

Datex Ohmeda Compact S5

The Datex S5 Compact monitor delivers anesthesia monitoring along with peace of mind, allowing for vital sign transmission and arrhythmia detection you can trust. While well suited for PACU and day surgery, with 6 user-configurable modes, the S5 Compact remains a diligent partner in all aspects of facility monitoring needs.

  • Ideally suited for PACU and day surgery monitoring
  • Small footprint bedside monitor with extra-large 12.1 inch color display
  • Large waveforms and numerics for easy viewing from long distances and multiple viewing angles • Basic hemodynamics and full airway gas measurements
  • Up to 8 waveforms and 4 numeric digit fields can be displayed
  • 24-hour graphical and numeric trends can be displayed and used to access historical data
  • Colour-coded prioritised and adjustable alarms that can be managed at the monitor or optionally from the S/5TM Network and Central
  • Optional extended arrhythmia analysis
  • Waveform snapshots to store and recall waveform samples for later analysis
  • Intuitive easy-to-use S/5 interface designed for the anesthesia care process
  • Six user-configurable display pages for each mode
  • S/5TM Device Interfacing Solution support for other patient care devices brings information to the Compact Monitor display screen
  • Rugged, shock resistant design offers a built-in battery and handle for intra-hospital transport monitoring with roll stand, wall and bed mounting options available
  • Integration of transport data with optional MemCardTM
  • Optional built-in, three-channel thermal array recorder
  • Compatible with Datex-Ohmeda S/5 Network and Central for monitor-to-monitor communication and centralising viewing

Datex Ohmeda Compact S5 Specifications


  • Display Size: 12.1 in diagonal
  • Display Type: Active matrix colour TFT LCD
  • Display Resolution: SVGA resolution, 800 x 600
  • Number of Waveforms: Up to 8
  • Number of Digit Fields: Up to 4
  • Display Layout and Colours: User-configurable
  • Integrated Command Board with direct function keys, menu keys and ComWheelTM for selections and adjustments in menus


  • Module Capacity: 2 2 module slots
  • I/O Connections: RS-232 computer serial output, 2 fixed analogue outputs, connector for remote controller, external keyboard and barcode reader with Y-cable, defibrillation sync, Nurse call
  • Device Interfacing Solution: Connector for up to 10 simultaneous S/5 DIS interfaces
  • Network: Compatible with Datex-Ohmeda S/5 Network and Central for monitor-to-monitor communication, centralised viewing and remote alarm management
  • Wireless Network Option: Allows the monitor to utilise both the wired and wireless network (WLAN) for centralised monitoring
  • MemCard Option: Activates MemCards to transfer the trended data of patient vital signs
  • Printing: Laser printing capabilities: serial printer supporting PCL5 language or network printer (serial/parallel converter, additional accessory)
  • Recorder Option: Built-in three-channel thermal array recorder • Mounting Options: Bed mount, wall mount and roll stand


  • Size: 13.2” W x 8.1” D x 13.4” H (335 x 205 x 340 mm)
  • Weight: 24.2 lbs/11 kg


  • Type: Built-in NiMH battery (original part number 17014-HEL, 2 required per unit)
  • Capacity: Up to 1.5 h typical on full charge at 23°C/73°C; with combination: M-NESTPR, M-miniC and N-CMW typically 2h
  • Recharging: When connected to main power
  • Charging Time: 10 hours to full capacity
  • Battery operation alarm: Early warning – ‘Battery low’ note, Final warning -’Battery low’ alarm
  • Battery state indicator: Battery bar for the 17017-HEL battery packs displayed on the screen


  • Alarm system classified into three categories according to priority in anesthesia; colour and audio tone coded
  • Central alarm display and adjustment page
  • 10 min graphical mini-trends referenced to set alarm limits


  • Modes: Up to 6 user-configurable modes for care-specific configurations
  • Pages: Up to 6 user-configurable display pages for each mode
