Cardiette AR600 ECG Compatible Medical Battery

£28.66 £34.39 Inc Tax

GTIN: N/A SKU: web EE050395 Category: Tags: ,


Euro Energy Part Number: EE050395
Cardiette AR600 ECG Compatible Medical Battery
Original Part Number: BATT/110236
Voltage / Capacity: 9.6 Volt 1.8 Ah
Dimensions: 65mm (L) x 31mm (W) x 51mm (H)
Approx. Weight: 300g
Chemistry: Nickel Metal Hydride (Ni-MH)

This is a compatible medical battery for use in the Cardiette AR600 ECG machine. Built in the UK by Euro Energy, this battery comes with a 12 month warranty.

About the AR600 ECG

The AR600 is a portable, entry-level electrocardiograph with an integrated high resolution thermal printer, LCD display showing program input and operating status and alphanumeric keyboard. The machine has two operating modes – manual and automatic – and is supplied with an internal rechargeable battery BATT/110236.

The AR600 is available in a basic version as well as a screen version for examining readouts before printing, and a Bluetooth version for data transmission via integrated Bluetooth interface.

Features and Benefits

  • Dual power supply system (mains and rechargeable internal batteries – battery part number BATT/110236)
  • Records ECG in automatic, manual and pre-programmed mode.
  • Prints the ECG signal in high resolution on 60mm paper with its thermal printer in various formats: 1, 2, 2 R and 3 channels.
  • Memorizes the last automatic ECG in automatic mode for later printout of copies as required.
  • Calculation of the main ECG parameters.

Technical Specifications

  • Mains Supply: Mains, with external power supply 230V±10% 50/60 Hz
  • Battery: Rechargeable battery pack NiMH 8 x 1.2 Vdc; 1800 mAh / battery part number BATT/110236
  • Applied Part: CF type
  • Input Dynamics: ± 300 mV @ 0 Hz.± 5 mV in pass band
  • Common Mode Rejection: > 100 MΩ on each electrode
  • Frequency Response: 0.05 / 150 Hz (-3dB)
  • Acquisition: 11 bit, 1000 samples/s/channel printing and filters, 500 samples/s/channel in calculation
  • Resolution: 5 µV/bit
  • Leads: 12 Standard or Cabrera leads
  • Signal Memory: 10 s for each lead in automatic mode
  • Recording Sensitivity:
    • Manual: 2.5 – 5 – 10 – 20 mm/mV ± 5%
    • Automatic: according to number of channels printed
  • Writing System: Thermal printer, 8 dot/mm
  • Print Channels: 3
  • Thermo-Sensitive paper:
    • Rolls: length 15 m, page 60×75 mm gridded
    • Z-Fold: length 18 m, page 60×75 mm gridded
  • Pacemaker Recognition: Recognizes pulse in accordance with current IEC standards
  • Filters: Mains interference : modified notch 50–60 Hz
  • Anti-Drift: 0.5 Hz high pass, linear phase
  • Keyboard: Membrane with functional simplified alphanumeric keyboard
  • Display: 120×32 pixel back-lit LCD
  • Operating Modes:
    • Manual: acquisition and printing in real time
    • Automatic: simultaneous acquisition; pre-programmed.
  • Diagnostics Program:
    • Parameter calculation
    • ECG interpretation (optional)
  • Standby Time: Internal battery BATT/110236: 3 hours in single channnel mode
  • Recharging Time: Internal battery BATT/110236 : 14 hours 100%
  • Dimensions: 250 x 60 x 185 mm (length x height x depth)
  • Weight: 8.2 lbs

For further information on this compatible medical battery, or to discuss our extensive range of compatible medical batteries, original manufacturer battery packs & OEM medical devices & accessories, contact our friendly and knowledgeable UK Customer Services team on Leicester 0116 2340567 or email

Additional information

Weight 0.3 kg
